B+S Black Waterless Wok Tables

Name: B+S Black Waterless Wok Tables
SKU: UFWWD
Availability: InStock

The B+S Black Waterless Wok Table is constructed on a stainless steel frame complete with a thick stainless steel plate ensuring long-lasting performance. This unit does not require water deck cooling.

The unit is powered by your choice of a 105Mj 24-jet chimney burner or 110Mj 18-jet duck burner both of which are fitted with flame failure as standard. Lever handle gas controls enable greater regulation of flame setting, which is essential during peak periods. A heavily insulated long skirt unflued cast iron eliminates radiant heat.

All external surfaces are made of AISI 304 grade stainless steel that is strong and durable. The deck is 1.5mm pressed top which allows for ease of cleaning around the ring area. A front waste gutter allows for additional ease of cleaning.

Model

Clear

SKU: UFWWD Categories: B+S Black, Cafes, Chinese, Hotels / Resorts, Indian, Institutions, Japanese, Korean, Malaysian, Quick Service Restaurants, Restaurants, Vietnamese, Waterless Wok Tables

Features and Benefits

AISI Grade Stainless Steel

Heavy duty complete stainless steel frame

Long skirt cast iron unflued ring – 340mm Diameter (UFWWD-1L 430mm Diameter)

Waterless feature eliminates the need for deck cooling

One-piece machine pressed top deck – 1.5mm Thick

Manually operated laundry arm and spindle

Heavy duty stainless steel lever action gas control

Flame Failure & Pilot – Included as standard

Front waste gutter allows for greater ease in cleaning

Perforated gutter cover and waste shovel included

Rear water pot included – 210mm W x 150mm D x 100mm H

Front access to all components makes service easy

Natural or LPG Gas

24 Jet Mongolian Chimney Burner (CB) or 18 Jet Duckbill Burner (DB)

24-month warranty

Optional extras

Side wing

Joining strip

Knee valve

Clip-on sauce wok prep table

B+S Black Single Hole Deluxe Waterless Wok Table

UFWWD-1

Dimensions (L x W x H): 600mm x 840mm x 1300mm

Gas Consumption (NG / LPG)

Chimney burners: 105Mj/h / 75Mj/h

Duckbill burners: 110Mj/h / 90Mj/h

Spec Sheet CAD Drawing

B+S Black Two Hole Deluxe Waterless Wok Table

UFWWD-2

Dimensions (L x W x H): 1200mm x 840mm x 1300mm

Gas Consumption (NG / LPG)

Chimney burners: 210Mj/h / 150Mj/h

Duckbill burners: 220Mj/h / 180Mj/h

Spec Sheet CAD Drawing

B+S Black Three Hole Deluxe Waterless Wok Table

UFWWD-3

Dimensions (L x W x H): 1800mm x 840mm x 1300mm

Gas Consumption (NG / LPG)

Chimney burners: 315Mj/h / 225Mj/h

Duckbill burners: 330Mj/h / 270Mj/h

Spec Sheet CAD Drawing

B+S Black One Hole Deluxe Waterless Wok Table With Two Side Burners

UFWWD-1SB2

Dimensions (L x W x H): 950mm x 840mm x 1300mm

Gas Consumption (NG / LPG)

Chimney burners: 145Mj/h / 115Mj/h

Duckbill burners: 150Mj/h / 130Mj/h

Spec Sheet CAD Drawing

B+S Black Two Hole Deluxe Waterless Wok Table With Two Side Burners

UFWWD-2SB2

Dimensions (L x W x H): 1550mm x 840mm x 1300mm

Gas Consumption (NG / LPG)

Chimney burners: 250Mj/h / 190Mj/h

Duckbill burners: 260Mj/h / 220Mj/h

Spec Sheet CAD Drawing

Description
Additional information

Description

AISI Grade Stainless Steel

Heavy duty complete stainless steel frame

Long skirt cast iron unflued ring – 340mm Diameter (UFWWD-1L 430mm Diameter)

Waterless feature eliminates the need for deck cooling

One-piece machine pressed top deck – 1.5mm Thick

Manually operated laundry arm and spindle

Heavy duty stainless steel lever action gas control

Flame Failure & Pilot – Included as standard

Front waste gutter allows for greater ease in cleaning

Perforated gutter cover and waste shovel included

Rear water pot included – 210mm W x 150mm D x 100mm H

Front access to all components makes service easy

Natural or LPG Gas

24 Jet Mongolian Chimney Burner (CB) or 18 Jet Duckbill Burner (DB)

24-month warranty

Additional information

Dimensions	N/A
Model	Large Single Hole Deluxe Waterless Wok Table, One Hole Deluxe Waterless Wok Table with Two Side Burners, Single Hole Deluxe Waterless wok Table, Three Hole Deluxe Waterless Wok Table, Two Hole Deluxe Waterless wok Table, Two Hole Deluxe Waterless Wok Table with Two Side Burners
